Visualization With Dynamic Axis Using Field Parameters

Contents

Introduction 2

Creating the Field Parameter 3

Visualizing with the Field Parameter 6

Visualizing a simple bar chart 6

Visualizing a column chart with Small Multiples 7

Changing the settings of the Field Parameter 9

Changing an existing field 9

Adding an additional field 11

Conclusion 13

Introduction

We may need to create multiple charts for the same metric to show the breakdown by different fields. For example, three different bar charts for Quantity Sold are broken by three different fields:

1. Product
2. Colour
3. Sales Person

This, of course, will consume the limited area that we have in our report canvas. Why don’t we instead combine all these 3 bar charts into one visual and allow the audience to toggle between the different breakdown fields? This can be done with the Power BI feature called Field Parameters in Power BI Desktop.

Creating the Field Parameter

The first thing you need to do is create the field parameters. In Power BI Desktop, in the ribbon, navigate to Modelling > New Parameter > Fields.

A configuration window will appear for you to customize your Field Parameter:

Name: This will be the name of the field parameter table
Fields: Fields/Columns that are available in the model that you can use as Field Parameters
Add and reorder fields: Columns that you selected in the Fields will appear here
Add slicer to this page: This will automatically create a slicer in your report canvas based on the field parameters.

Once you select the columns that you would like to use as the Field Parameters, it will appear in the Add and Reorder field box. In this tutorial, the fields are Colour, Category and Sales Person.

Note that although you can choose any columns from any tables in your data model, whether it is from the fact or dimension table, for this tutorial, use only columns that will not be aggregated.

After you click Create, the first thing you may see on your report canvas is a slicer containing the fields you have selected.

But if you review the data model, a table called Parameter has been added to your data model. This is a stand-alone table that will not have any relationship with any other tables in your data model.

Once this table is created, you can now proceed to using the field parameters in your visualizations.

Visualizing With the Field Parameter

Visualizing a simple bar chart

Let’s go back to the report canvas with the slicer that contains the field parameters. Now add a bar chart with the following configurations:

Y-axis: Column Parameter from the Parameter table
X-axis: Any measure you like to visualize ( in this tutorial, we will use Quantity, which is then renamed to Quantity Sold in the X-axis )

And just like that, you have created a bar chart with a dynamic field. Simply click on the slicer, and the breakdown in the bar chart will reflect the selection.

Visualizing a Column Chart With Small Multiples

Now, let’s create a column chart with the following configurations:

X-axis: Date column
Y-axis: Quantity Sold
Small Multiples: Parameter

Your result will look like the following.

The Small Multiples breakdown will now reflect the selection in the slicer. Due to the nature of Small Multiples, you can also select multiple fields in the parameter to have a more specific breakdown of the metric.

Changing the settings of the Field Parameter

Changing an existing field

The Field Parameter settings pop-up window will only appear the first time you create it. You will not be able to return to the settings window after. To make any adjustments, for example, adding or changing existing field parameters, you will need to know a bit of DAX.

The field parameter table is basically a calculated table created using DAX. You can see the DAX syntax by clicking on the Parameter table.

We can make changes to the field parameter just by adjusting the DAX syntax for the calculated table. For example, if we would like to replace Colour with Date, we can adjust the syntax to the following:

The red box on the left will be the name that will appear on the table; you can name it however you like. In the red box on the right, you will need to specify the column and table name you would like to use as the new field. Once the changes have been made, they will be reflected in the table view and the slicers in your report canvas.

Adding a Field

To add a new field, we first need to add a blank line in the syntax between lines 4 and 5. Go to the end of line no 4 and hit Shift-Enter.

Then, add a comma at the end of line 4.

Now, it is time to add a new field. In this tutorial, we will add Date.

Please note that for the last field, you do not need to add a comma at the end of the line. The number that appears at the end of every line is the sequence order for the fields in the slicer/visuals, ie. A field with zero appears at the top of the list, followed by 1 and 2 and so on. Make sure these numbers are unique.

Once you hit enter, the new field will appear in your report canvas.

Conclusion

Field Parameter is a great way to visualize different fields in the same visual, and it can be used with the majority of the visuals available in Power BI desktop that have the following fields:

1. X-axis
2. Y-axis
3. Columns
4. Rows
5. Legend
6. Small Multiple
7. Category

Based on your creativity, you can create very interactive visuals in your report to entice and improve the user’s experience.
